SUPPORT PANELS REAR
Part Breakdown Image

Fig #

1
REAR FLOOR PAN

REAR FLOOR PAN

Part Number: U1005A-I

REAR FLOOR PAN

$  271.56

2
0

0

Part Number: U1003L-I

(REPLACED BY U1003L-J) INSIDE TAIL LEFT


3
INSIDE TAIL RIGHT

INSIDE TAIL RIGHT

Part Number: U1003R-L

INSIDE TAIL RIGHT

$  79.64

4
OUTSIDE TAIL LEFT

OUTSIDE TAIL LEFT

Part Number: U1004L-F

OUTSIDE TAIL LEFT

$  67.65

5
OUTSIDE TAIL RIGHT

OUTSIDE TAIL RIGHT

Part Number: U1004R-F

OUTSIDE TAIL RIGHT

$  67.65

6
REAR FLOOR PAN WING SUPP. L.

REAR FLOOR PAN WING SUPP. L.

Part Number: U1007L-B

REAR FLOOR PAN WING SUPPORT LEFT.

$  31.76

7
REAR FLOOR PAN WING SUPP. R

REAR FLOOR PAN WING SUPP. R

Part Number: U1007R-B

REAR FLOOR PAN WING SUPPORT RIGHT

$  31.76

8
WIDTH SUPPORT CHANNEL

WIDTH SUPPORT CHANNEL

Part Number: U1021A-E

WIDTH SUPPORT CHANNEL

$  34.32

9
TAIL SUPPORT SPACER TUBE

TAIL SUPPORT SPACER TUBE

Part Number: U1171A-B

TAIL SUPPORT SPACER TUBE

$  43.92
