DUMP BOX BIN CARRIAGE

Hotspots

Fig #

1

DUMP BOX BIN CARRIAGE

Part Number: F2241A-A

DUMP BOX BIN CARRIAGE (4 TUBE FRAME)

$ 1,619.72

2

DUMP BOX CARR. MNT. STIFF.

Part Number: F2245A-OO-BLK

DUMP BOX CARRIAGE MOUNT STIFFENER

$ 193.85

3

BEARING

Part Number: F2212A-N

DUMP BOX PILLOW BLOCK/STEEL BALL BEARING

4

3/8" SAE WASHER

Part Number: U8590A-N

3/8in SAE WASHER

$ 0.05

5

SCREW

Part Number: U8724A-N

3/8-16 X 4.5in HEX HEAD CAP SCREW

$ 1.65

6

3/8-16 NYLON LOCK NUT

Part Number: U8560A-N

3/8-16 NYLON LOCK NUT

$ 0.17

7

PLASTIC DUMP BOX

Part Number: F2210A-N

1.75 CUBIC YARD PLASTIC DUMP BOX

8

DUMP BOX BIN F SUPP. RAIL

Part Number: F2216A-OO

DUMP BOX BIN FRONT SUPPORT RAIL

9

DUMP BOX BIN SIDE SUPP.

Part Number: F2215A-OO

DUMP BOX BIN SIDE SUPPORT RAIL

10

5/16" SAE WASHER

Part Number: U8585A-N

5/16in SAE WASHER

$ 0.03

11

SCREW

Part Number: U8564A-N

5/16-18 X 3/4in HEX HEAD CAP SCREW

$ 0.13

12

NUT

Part Number: U8510A-N

5/16-18 SERRATED FLANGE HEX NUT

$ 0.12
