Fig #
Part Number: U5704A-A
1/O 33 CONTACTOR TO CONTROLLER (AC & DC) CONT TO MOTOR (DC)
Part Number: U5702A-A
1/O 20.5POS. BATTERY TO FUSE (WET CELL AC AND DC)
Part Number: U5719A-A
EYELET POS. BATTERY TO FUSE (AGM AC AND DC)
Part Number: U5701A-B
NEG.MAIN DISC. TO CONTROLLER (AC AND DC)
Part Number: U5706A-B
#1/0 43 CONTROLLER TO MOTOR (DC ONLY *2 EA)
Part Number: U5707A-A
#6 36 CONTROLLER TO MOTOR (DC ONLY *2PER)
Part Number: U5703A-C
16 1/0 BATTERY CABLE 5/16 EYELETS (DC AND AC)
Part Number: U5705A-A
#1 49 POS. CONTROLLER TO MOTOR (DC ONLY)
