DOOR OUTER
Part Breakdown Image

Fig #

1L
HANDLE ONLY

HANDLE ONLY

Part Number: F3517L-N

HANDLE ONLY (OUTER HANDLE) LH

$  27.08

1R
HANDLE ONLY

HANDLE ONLY

Part Number: F3517R-N

HANDLE ONLY (OUTER HANDLE RH)

$  26.95

2
SELF DRILLING PHIL PAN

SELF DRILLING PHIL PAN

Part Number: U8641A-N

8-18 X 1/2in SELF DRILLING PHIL PAN

$  0.16

3
SCREW

SCREW

Part Number: U2856A-N

#10X3/4 HEX SELF DRILL AND TAP

$  0.32

4L
LEFT SIDE MIRROR

LEFT SIDE MIRROR

Part Number: U3612L-N

LEFT SIDE MIRROR (LEFT HAND DRIVE)

$  41.51

4R
RIGHT SIDE MIRROR

RIGHT SIDE MIRROR

Part Number: U3612R-N

RIGHT SIDE MIRROR (LEFT HAND DRIVE)

$  42.40

5
GLASS WIPER SEAL

GLASS WIPER SEAL

Part Number: KIT-44

GLASS WIPER SEAL (EXV2 Patriot)

$ 10.26

6
LOCK CYLINDER ROTATIONAL TAB

LOCK CYLINDER ROTATIONAL TAB

Part Number: F2276A-OO-BLK

LOCK CYLINDER ROTATIONAL TAB

$  3.29

7
BEARING

BEARING

Part Number: F2828A-N

FLANGED SLEEVE BEARING 1/4 SHAFT 3/8 OD

$  3.14

8
LOCK CYLINDER LINKAGE TAB

LOCK CYLINDER LINKAGE TAB

Part Number: F2275A-OO-BLK

LOCK CYLINDER LINKAGE TAB

$  9.62

9
SCREW

SCREW

Part Number: U2841A-N

1/4-20 X 1/2 TRUSS HEAD MACHINE SCREW

$  0.16

10
LINKAGE ROD END CLIP L

LINKAGE ROD END CLIP L

Part Number: F2826A-N

LINKAGE ROD END CLIP 1/4 IN LEFT

$  2.86

11
DOOR FLANGE BULB SEAL (1 FOOT)

DOOR FLANGE BULB SEAL (1 FOOT)

Part Number: U2868A-N

DOOR FLANGE BULB SEAL (SOLD BY FOOT)

$  4.40

12
SCREW

SCREW

Part Number: U8707A-N

SS 1/4-20 X 1 PHIL FLAT HEAD MACHINE SCREW

$  1.04

13L
PATRIOT L OUTER DOOR PANEL

PATRIOT L OUTER DOOR PANEL

Part Number: F2701L-OO

PATRIOT LEFT OUTER DOOR PANEL (W/BONDED BRACKETS)


13R
PATRIOT R OUTER DOOR PANEL

PATRIOT R OUTER DOOR PANEL

Part Number: F2701R-OO

PATRIOT RIGHT OUTER DOOR PANEL (W/BONDED BRACKETS)


14
EXV2 LOCK AND SWITCH KIT

EXV2 LOCK AND SWITCH KIT

Part Number: F3519A-OO

EXV2 LOCK AND SWITCH KIT

$  84.96
